Required Tools:
Phillips Head Screwdriver
3/8” Nut Driver (or Socket Wrench)
11/32” Nut Driver (or Socket Wrench)
Fasteners That May Be Required:
3
#10-32 x 5/8” Phillips
Machine Screw #10-32 x 3/8” Phillips
Pan Head Screw
#10-32 Keps Locking Nut #10-32 Clip Nut
SRX2 & SRX3 Parts List
Item Description Qty.
1 #10-32 x 5/8" Screw 12
2 #10-32 x 3/8" Screw 8
3 #10-32 Keps Locking Nut 8
4
4 5
12 #10-32 Clip Nut
Stationary Shelf Bracket
Stationary Shelf Bracket
Rack Mount Fixed And Roll-Out Shelves
SRX2, SRX3 and SRX4
Cable Management Arm
(included with SRX4 only)
SRX4 Parts List
Item Description Qty.
1 #10-32 x 5/8 Screw 16
2 #10-32 Clip Nut 16
3 Slide Bracket 2
4
2 5
1 Warning Label
#8-32 x 3/8 Screw
2 6 #8-32 Keps Locking Nut
1 7 Cable Management Arm
#8-32 x 3/8" Phillips Pan
Head Machine Screw #8-32 Hex Lock Nut
