RADIO PARAMETERS
Frequency of Operation 5725-5845 MHz (ISM band)
Channels 6 non-overlapping, software selectable
Channel Spacing 20 MHz
RF Power Output +21 dBm Max Setting (6 Mbps mode)
+17 dBm Max Setting (54 Mbps mode)
Modulation Format OFDM
Modulation Speeds 6, 12, 18, 24, 36, 48 and 54 Mbps; User selectable
Certifi cation / Compliance FCC Part 15.247, 15.407
Receiver Sensitivity (BER 10-6) -92 dBm (6 Mbps mode) to -73 dBm (54 Mbps mode) typical
DATA AND OPERATIONAL PARAMETERS
User Data throughput 5 Mbps (6 Mbps mode) to 45 Mbps (54 Mbps mode)
Upstream/Downstream Throughput Dynamic, automatically adjusts to suit demand
Bandwidth Control Asymmetrical MIR bandwidth control
Latency < 5 ms
Interference Handling Forward Error Correction (FEC) & Automatic Retransmit Request (ARQ)
Security Proprietary MAC address authentication; over the air data scrambling; two level password control.
Encryption 128-bit STEP (Secure Trango Encryption Protocol)
Confi guration & Management Telnet, SNMP, HTTP; TFTP server daemon for fi rmware upgrades; Built-in Link Performance tests;
Remote temperature and input voltage measurement
ANTENNA PARAMETERS
Internal Antenna Integrated 23 dBi 9° × 9° patch dual-polarized (HPOL/VPOL), Electrically selectable polarization
External Antenna (Optional) 28 to 34 dBi dual-polarized dish antennas, 2- to 4-ft. diameter
POWER PARAMETERS
Power Method Power-over-Ethernet (PoE Injector J-Box included)
Voltage Input 10.5 VDC - 24 VDC Max; Input voltage measurement via Telnet, SNMP, HTTP
Standard Power Supply Universal 24VDC/750mA, 90-260VAC/50-60Hz
PoE Cat-5 Max Cable Length 100 meters on 24 AWG STP Cat-5 cable
Power Consumption < 15 W
PHYSICAL AND ENVIRONMENTAL
Ethernet Interface RJ45, 10/100BaseT, IEEE 802.3 Ethernet compliant, auto-sense, auto-negotiate
External Antenna Connector SMA reverse polarity (-EXT Models only)
Reset Button Resets password and IP confi guration
Radio Enclosure All-weather, powder coated, heavy duty aluminum construction with conduit adapter
Temperature Range -40° to 60° C (-40° to 140° F); Temperature measurement via Telnet, SNMP, HTTP
Radio Weight 7 lbs (ATLAS5010-INT with integrated Patch Panel Antenna)
3 lbs (ATLAS5010-EXT stand-alone radio)
Radio Dimensions 15” × 15” (ATLAS5010-INT with integrated Patch Panel Antenna)
7” × 7” (ATLAS5010-EXT stand-alone radio)
All specifi cations are typical and subject to change without notice.
COMPATIBILITY / RANGE CHART
Model / Part Number Model Type Antenna Range / Fade Margin*
ATLAS5010-INT Radio with integrated antenna Internal, 23 dBi 6 miles @ 45 Mbps / 10 dB
ATLAS5010-EXT Radio with connection for external antenna External, 34 dBi or other 20 miles @ 45 Mbps / 18 dB
* At 5.8 GHz with maximum RF modulation speed. Adaptive modulation enables longer range links up to 40 miles at lower speeds.
Atlas 5010 Series ™ 45 Mbps Point-to-Point Wireless Ethernet Bridge
Specifi cations
