PARTS INFORMATION
[email protected] Page 4
THT-2120
FUEL SYSTEM • FIGURE 3
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
3-25 40306500200 GASKET,INTAKE 1
3-26 4040650090 SET,CARB INSULATOR 1 Includes gasket
3-27 99416050252 SCREW,5X25WS 2
3-30 40206500200 GASKET,CARBURETOR 1
3-33 99967015000 O-RING,P15 1
3-35 4230650081 BODY,CLEANER 1
3-36 47006500200 COLLAR 2
3-37 52806500200 LEVER,CHOKE 1 ~R233951
3-37 5280650T20 LEVER,CHOKE 1 R233952~
3-38 99204080030 WASHER,8 1
3-39 47601700200 BOARD,BLOW OVER CHECK 1
3-40 99210050012 WASHER,S,5 2
3-41 99011050602 SCREW,5X60 2
3-43 4460650020 ELEMENT,CLEANER 1
3-44 4520650091 COVER,CLEANER,W/BOLT 1
3-45 3800637C200 BOLT,CLEANER COVER 1
3-50 70053005130 PIPE,FUEL 1 ~R107151
3-50 2230650090 PIPE,FUEL,ASS'Y 1 R107152~
3-51 68000731201 CLIP 6.3 1
3-52 6750404280 FILTER,FUEL 1
3-53 5910650000 TANK,FUEL 1 ~T218560 One hole
3-53 5910661321 TANK,FUEL 1 ~U217438 Two hole
3-53 5910651A21 TANK,FUEL 1 U217439~ Three hole
3-54 5950650A90 CAP,TANK 1 ~T218560
3-54 5950656B90 CAP,FUEL BLACK,NON VENT 1 T218561~
3-55 65900801200 COLLAR 2
3-58 99463050185 BOLT,HEX 5X18PS 2
3-70 44225143800 PUMP,PRIMING ASS'Y 1 U217439~
3-77 7000250408 PIPE,FUEL,2.5x4x80 1 U217439~
3-78 7000250406 PIPE,FUEL,2.5X4X65 1 U217439~
3-79 53432710200 GROMMET,FUEL PIPE 1 U217439~
3-121 5640661190 VENT,AIR ASS'Y 1 U217439~
3-122 5650441020 PIPE,AIR VENT 1 U217439~
3-123 6460661290 VALVE 1 T218561~
