Turbosound Milan Mi0 - Manual (Page 23)

user manual
MILAN Mi0
MILAN Mi0 user manual
Page 23
Technical Specifications
Milan Mi0
Dimensions 515mmH x 330mmW x 293mmD
(20.3” x 13” x 11.5”)
Net weight 11.8kg (26lbs)
Frequency range 55Hz – 20kHz ±3dB
Dispersion 90°H x 60°V @ -6dB points
Max SPL (cont/max) 119dB/125dB
Construction Injection-moulded polypropylene enclosure, self-coloured in
dark blue. Recessed carrying handle. Integral dual-angle pole
mount socket. Powder coated galvanised perforated steel
mesh grille
Connectors Mic input: female XLR wired pin 2 hot
Line input: combo jack/female XLR wired pin 2 hot
Mix out: XLR male wired pin 2 hot
IEC mains conector with integrated fuseholder
Controls Mic gain
Line level
Mains on/off
Bass and treble controls
Ground lift switch
Indicators SIG/LIMIT LED
Power LED (green)
Rigging options 6 x M10 threaded internal rigging points
