MILAN Mi0
MILAN Mi0 user manual
Page 16
Stereo PA with an external mixer
Two Milan loudspeakers form the left and right elements of a stereo PA setup with all signal
sources connected to an external mixing console. Connect the outputs of the mixer to the Mi0 line
inputs using either balanced XLR cables, or balanced or unbalanced jack cables. Bring up the
master faders on the mixer, ensuring that the outputs are not clipping, and then adjust both
loudspeakers’ level controls to the desired loudness. For consistent balance and response set the
tone controls to approximately the same positions on both cabinets.
MIC GAIN
POWER
ON
BASS TREBLE
MIC IN MIX OUT GROUND LIFT LINE IN
LINE LEVEL ON
MAX MIN + - + - MAX MIN
LIMIT MIC GAIN
POWER
ON
BASS TREBLE
MIC IN MIX OUT GROUND LIFT LINE IN
LINE LEVEL ON
MAX MIN + - + - MAX MIN
LIMIT
LEFT RIGHT
