Troy-Bilt STORM Series - Manual (Page 23)

3
9
Illustrated
Parts List
To order replacement
parts, call
1-800-648-6776
or visit
www.troybilt.com
1. 631-04133 Handle Assembly, Lock, LH
2. 631-04134A Handle Assembly, Lock, RH
3. 684-04105A Handle Ass’ y, Engagement LH
4. 684-04106A Handle Ass’y, Engagement, RH
5. 710-0224 Screw, #10-16, 0.500
6. 710-04586 Screw, 1/4-20, 1.625
7. 710-1233 Screw, Machine, #10-24, 1.375
8. 712-04064 Nut, Flange Lock, 1/4-20, Nylon
9. 720-0274 Grip, 1.0 ID x 5.0
10. 720-04039 Knob, Shift
11. 731-05334 Handle Panel, N-Style
12. 732-0193 Spring, .39 x .60 x .88
13. 735-0199A Bumper, Rubber, .62 OD x .22
14. 736-0267 Washer, Flat, 385 x .87 x .06
15. 738-04122 Screw, Shoulder, .43 x 1.34, 1/4-20
16. 738-04125 Screw, Shoulder, .374 Dia. x 1.05
17. 746-04227A Cable, Speed Selector
18. 746-0605 Barrel Holder, Cable, LH
19. 790-00248 Bracket, Panel
20. 790-00203 Lever, Shift
21. 684-04104 Crank Assembly, Chute
22. 710-0449 Screw, Carriage, 5/16-18, 2.25
23. 710-1260A Screw, 5/16-18, 0.75, Gr5
24. 714-0104 Pin, Cotter, .072 x 1.13
25. 720-0201A Crank Knob, 1.0 Dia. x 3.2, Black
26. 720-04072 Star Knob
27. 726-0100 Cap, Push, 3/8 Rod
28. 735-0234 Grommet, .44 ID x .94 OD x .50
29. 736-0185 Washer, Flat, .375 x .738 x .063
30. 747-04263 Eye Bolt, Chute Crank
31. 749-04138 Handle, Lower
32. 749-04141 Handle, Upper, RH
33. 749-04142 Handle, Upper, LH
34. 731-04912A Chute, Lower, 5.0 Diameter
35. 710-0276 Bolt, Carriage, 5/16-18, 1.0
36. 712-04063 Nut, Flange Lock, 5/16-18, Nylon
37. 710-04071 Bolt, Carriage, 5/16-18, 1.0
38. 710-0451 Bolt, Carriage, 5/16-18, .750
39. 731-04426A Chute, Upper, w/ Label
40. 736-0159 Washer.349 ID x .879 OD x .063
41. 741-0475 Bushing, Plastic, .380
42. 784-5647 Bracket, Chute Crank
43. 731-04869 Flange Keeper, Chute
44. 732-04238* Torsion Spring
45. 712-04081A* Nut, Hex, 1/4-20
46. 731-04894B* Lock Plate
47. 710-04354*
Cap Screw 1/4-20 x .375
48. 711-04287* Pivot Rod
49. 731-04896A* Clutch Lock Cam
50. 732-04219A* Clutch Lock Spring
51. 710-04326*
Screw #8-16 x .50
This Operator’s Manual
may cover a range of
product specifications
for various models.
Characteristics and fea-
tures discussed and/or
illustrated in this manual
may not be applicable to
all models.
*Available on units equipped with clutch lock feature.
NOTE: Snow thrower features/components vary by model. NOT all parts listed above and pictured on the previous page are
standard equipment.
