Installation – Tripp Lite B004-DUA4-K-R User Manual
Page 4

4
Notes: Before you begin, power off all devices that you will be connecting
to the KVM switch. You must also unplug the power cords of any computers
that have the Keyboard Power On feature. There is a 3.5mm port on the
front of the B004-DUA4-K-R for use with an optional wired remote control.
1. Connect the external power supply to the KVM, and then plug it into
a Tripp Lite Surge Suppressor, Uninterruptible Power Supply (UPS), or
Power Distribution Unit (PDU).
2. Connect your USB keyboard and mouse to the two USB ports on the left of
the KVM switch. (The two USB ports on the right are for peripheral devices.)
3. Connect a microphone and speakers to the corresponding 3.5mm
stereo ports.
4. Connect your DVI monitor to the DVI console port on the KVM.
Note: If you are connecting to a VGA monitor, use Tripp Lite’s DVI to
VGA adapter cable, model P556-006
5. If you are connecting USB peripherals, plug them into the two USB 2.0
ports on the right. (The two USB ports on the left are for the shared
keyboard and mouse.) The B004-DUA4-K-R includes an additional two
USB 2.0 peripheral ports on the front of the unit.
6. Using the included DVI + Audio KVM cable kits and USB A/B cables,
connect the computer ports on the KVM to a computer.
Note: If you are connecting to a computer with a DVI-D port, use a
Tripp Lite DVI-I to DVI-D adapter, model P118-000.
7. Power on the connected computers and devices.
Installation
