2 Installation BCS II Simplex Repeater User Manual
2-4 Telect, Inc. 117209-1 A0
Transmit Settings by Cable Type
Receive Settings by Cable Type
Cable
Repeater to NE
distance (feet)
Setting
720
0-124 Low
124-255 High
728
0-212 Low
212-425 High
734
0-224 Low
224-450 High
735
0-112 Low
112-225 High
RG-59
0-224 Low
224-450 High
Cable
Cross-connect
distance (feet)
Setting
720
0-124 Short
124-255 Long
728
0-212 Short
212-425 Long
734
0-224 Short
224-450 Long
735
0-112 Short
112-225 Long
RG-59
0-224 Short
224-450 Long
