TD-8816 ADSL2/2+ Ethernet Router User Guide
48
Appendix A: Specification
General
Standards and Protocols
ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, ITU G.992.5
IEEE 802.3, IEEE 802.3u, TCP/IP, PPPoA , PPPoE, SNTP, HTTP,
DHCP, ICMP, NAT,CWMP
Safety & Emission FCC、CE
Ports
1 10/100M Auto-Negotiation RJ45 port（Auto MDI/MDIX)
1 RJ11 port
LEDs
LAN, ADSL
Power, ACT
Network Medium
10Base-T: UTP category 3, 4, 5 cable
100Base-TX: UTP category-5
Max line length: 6.5Km
Transmit data-rate
Max download data-rate: 24Mbps
Max upload data-rate: 1Mbps
System Requirement
Internet Explorer 5.0 or later, Netscape Navigator 6.0 or later
Win 9x/ME/2000/XP/Vista
Power
Input: 9VAC/0.8A, 50Hz or 60 Hz
Power: 4W (maximal)
Physical and Environment
Working Temperature 0℃ ~ 40℃
Working Humidity 10% ~ 90% RH (non-condensing)
Storage Temperature -40℃ ~ 70℃
Storage Humidity 5% ~ 90% RH (non-condensing)
