Arbitrary Waveform Generators

AWG520

Arbitrary Waveform Generators

www.tektronix.com/signal_sources

3

Auxiliary Outputs

Marker –
Number: AWG520: 4.
Level:

Hi/Lo: –2.0 V to 2.0 V (0.05 V

p-p

to 4 V

p-p

)

into 50

Ω; –4.0 V to 4.0 V (0.1 V

p-p

to 8 V

p-p

)

into 1 M

Ω.

Resolution: 0.05 V.
Accuracy: Within ±0.1 V ±5% of setting.
Rise/Fall Time (10 to 90%, typical):

At 1 V

p-p

, Hi +0.5 V/Lo –0.5 V: 0.5 ns.

At 2 V

p-p

, Hi +1 V/Lo –1 V: 1.0 ns.

At 4 V

p-p

, Hi +2 V/Lo –2 V: 2.0 ns.

Variable Delay:

Range: 0 ns to +2 ns.
Resolution: 20 ps.

Marker Skew: 32 ps.
Connector: Rear-panel SMB.

Clock Out –
Level: ECL 100 K compatible.
Connector: Front-panel BNC.

Noise –
Level:

Range: –145 dBm/Hz to –105 dBm/Hz.
Resolution: 1 dB.
Accuracy: ±2.5 dB at 100 MHz.
Flatness: ±2.5 dB, 1 MHz to 300 MHz
(referenced to –105 dBm/Hz at 100 MHz).

Type: Gaussian.
Connector: Front-panel BNC.

Digital Data Out (Opt. 03) –
Output Signals: D0 to D9 (10-Bits).
Level:

Hi/Lo: –2.0 V to 2.0 V (0.1 V

p-p

to 4 V

p-p

) into

50

Ω; –4.0 V to 4.0 V (0.2 V

p-p

to 8 V

p-p

)

into 1 M

Ω.

Resolution: 0.1 V.
Accuracy: Within ±0.1 V ±5% of setting.

Rise/Fall Time (10 to 90%) typical:

At 1 V

p-p

, Hi +0.5 V/Lo –0.5 V: 0.5 ns.

At 2 V

p-p

, Hi +1 V/Lo –1 V: 1.0 ns.

At 4 V

p-p

, Hi +2 V/Lo –2 V: 2.0 ns.

Skew Between Data:

≤1 ns, 330 ps typical.

Delay:

Data to marker: 4.4 ns.
Clock to data: 3.7 ns.

Connector: Rear-panel SMB.

Auxiliary Inputs

Trigger In –
Impedance: 1 k

Ω or 50 Ω.

Polarity: POS or NEG.
Input Voltage Range:

1 k

Ω: ±10 V.

50

Ω: ±5 V.

Threshold:

Level: –5.0 V to 5.0 V.
Resolution: 0.1 V.
Accuracy: ±(5% of level + 0.1 V).

Pulse Width (0.2 V amplitude): 10 ns minimum.
Trigger Holdoff: 500 ns maximum.
Delay to Marker: 30 ns +1 clock.
Connector: Front-panel BNC.

Event Trig Input –
Number of Events: 4 Bits.
Input Signals: 4 event bits, strobe.
Threshold: TTL level.
Pulse Width: 64 clocks minimum.
Maximum Input: 0 V to +5 V (DC + peak AC).
Delay to Analog Out:

≤384 clock +20 ns.

Impedance 2.2 k

Ω, pull-up to +5 V.

Connector: Rear-panel 9-Pin D-sub.

CH1 ADD Input –
Input Voltage Range: –1 V to 1 V (DC + peak AC).
Impedance: 50

Ω.

Bandwidth (–3 dB): DC to 200 MHz at 1 V

p-p

input.

Amplitude Accuracy: ±5%.
Connector: Front-panel BNC.

Reference 10 MHz Clock IN –
Input Voltage Range: 0.2 V to 3.0 V

p-p

,

±10 V maximum.
Impedance: 50

Ω, AC coupled.

Frequency Range: 10 MHz ±0.1 MHz.
Connector: Rear-panel BNC.

External Sample Clock In

Input Voltage Range – 0.25 V

p-p

to 1 V

p-p

.

Maximum Input Voltage Range – ±10 V

max

.

Impedance – 50

Ω, AC coupling.

Frequency Range – 10 MHz to 900 MHz.

Duty Cycle Ratio – 40% to 60%.

Pulse Width – 0.5 ns minimum.

Connector – Rear panel BNC.

Display

Area – 13.2 cm (5.2 in.) horizontal by 9.9 cm
(3.9 in.) vertical.

Resolution – 640 horizontal by 480 vertical pixels.

Data Storage

Internal Hard Disk Drive – 10.0 GB (standard).

Floppy Disk Drive – 3.5 in., 1.44 MB.

Option 10 – Substitute flash disk (128 MB) for HDD,
add standby switch. (Opt. 10 is best suited for ATE
and system usage requiring 7x24 hour operation.)

Option 11 – Substitute Internal Hard Disk Drive
with removable 10.0 GB Hard Disk Drive mounted
on top of the instrument

Environmental, EMC, Safety

Temperature –
Operating: 10 ºC to +40 ºC.
Nonoperating: –20 ºC to +60 ºC.

Humidity –
Operating: 20 to 80%, noncondensing.
Nonoperating: 5 to 90%, noncondensing.

Altitude –
Operating: Up to 4,500 m. (15,000 ft). Maximum
operating temperature decreases 1 ºC per 300 m
above 1.5 km.
Nonoperating: Up to 15,000 m (50,000 ft.).

Vibration (test limits) –
Operating: 0.27 G

RMS

from 5 to 500 Hz, 10 minutes

duration.
Nonoperating: 2.28 G

RMS

from 5 to 500 Hz,

10 minutes duration.

Shock (test limits) –
Nonoperating: 294 m/s

2

(30 G), half-sine,

11 ms duration.

EMC Compliance –
EN50081-1.
EN50082-1.
FCC Part 15, Subchapter B Class A.
AS/NZS 20641/2.

Safety – UL3111-1, CSA1010.1, EN61010-1,
IEC61010-1.

Power

Source Power –
Line Voltage Range: 100 to 240 VAC.
Line Frequency: 48 to 63 Hz.

Power Consumption – 600 W at 8 A maximum.

Physical Characteristics
Dimensions

mm

in.

Height

178

7.0

Height with Opt. 11

215.5

8.48

Width

422

17.5

Depth

560

25.8

Weight

kg

lbs.

Net

17

37.5

Warranty – One year parts and labor.

Other

Programmable Interface –
GPIB: 24-Pin IEEE488.1 connector.
Ethernet: 10Base-T, RJ-45 connector.

Keyboard Connector – 6-Pin mini-DIN connector.
