Toshiba RSAP User Manual
Page 8
8
1 AC Input L1 (option)
2 AC Input L2 (option)
5 BYPASS
6 BYPASS COMMON
7 INVERTER
8 INVERTER COMMON
9 ON BATTERIES
10 ON BATTERY COMMON
11 RECTIFIER
12 RECTIFIER COMMON
13 UPS FAILURE
14 UPS COMMON
15 LOW BATTERY
16 LOW BATTERY COMMON
17 OVERLOAD
18 OVERLOAD COMMON
TERMINAL BLOCK DESCRIPTION
(LOCATED INSIDE BOX)
FIGURE 2.1
(INTERNAL POWER SUPPLY / HARDWIRE OPTION)
TB 1
3 BYPASS
4 BYPASS
