PARTS INFORMATION
[email protected] Page 4
TPS-200/210
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
4-30 3433233180 SHAFT,DRIVE 1
4-31 3413233180 PIPE,DRIVE SHAFT 1
4-32 34737601900 BUSHING 1
4-33 99461050254 BOLT,HEX HOLE,5X25S 1
4-34 5123370081 KNOB,HANDLE 1 Before S/N V021700
4-34 5123338P20 KNOB,HANDLE 1 S/N V021701 and after
4-35 2803233120 CASE,JOINT 1
4-36 3523233180 PIN,LOCK 1
4-37 99021060351 BOLT,6X35 1 Before S/N V021700
4-37 99021060501 BOLT,6X50 1 S/N V021701 and after
4-38 99051050103 BOLT,HEX.HOLE,5X10 1
4-39 99101050041 NUT,5 1
4-40 99350010002 RING,STOP,C-10 EX 1
4-41 99961690001 BEARING,BALL,#6900ZZ 1
4-42 34833130200 COLLAR,B 1
4-44 35902103200 WASHER,CLUTCH,B 1 S/N V021701 and after
4-45 99101060011 NUT,6 1 S/N V021701 and after
4-46 99143060023 NUT,6 1 S/N V021701 and after
DRIVE SHAFT & COUPLING • FIGURE 4
