PARTS INFORMATION
[email protected] Page 1
TPS-200/210
OIL PUMP, CAP, FILTER • FIGURE 1
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1-1 0413230400 OIL TANK COVER SET 1
1-2 0313230420 COLLAR 3 4
1-3 4223230421 GASKET,OIL TANK 1
1-4 99967005000 O-RING,P5 1
1-5 3823230420 BOLT,STEP,A 1
1-6 1443230490 OIL PUMP ASSY 1
1-7 99967005000 O-RING,P5 1
1-8 4493230420 SPRING,OIL PUMP 1
1-9 0733230481 PISTON,OIL PUMP 1
1-11 7005300506 PIPE,FUEL 3X5X60 1
1-12 99416040121 SCREW,4X12 4
1-13 99201050011 WASHER,5 1
1-14 48732712201 FILTER,OIL 1
1-15 4863234590 FILTER ASSY,FINE MESH 1
1-16 7005300507 PIPE,FUEL 3X5X75 1
1-17 9923008000 NUT,PUSH 1 Y161651~
1-20 5013230421 ADJUSTER,OIL PUMP 1
1-21 99967005000 O-RING,P5 1
1-22 99355060001 RING,STOP,6 1
1-30 6243230492 CAP,OIL TANK 1
1-31 0823230420 BANJO,OIL PUMP 1
1-35 99967015000 O-RING,P15 1
1-36 5660406320 COVER,AIR VENT 1 ~U231876
1-55 99201020011 WASHER,2 1 V196951~
1-56 99967001413 O-RING 1 V196951~
