Tunturi J4F - Manual (Page 10)

70 70
1 233 4027 User interface (incl. 118) 1
2 173 4070 Handle bar cover, R pair 1
3 173 4071 Handle bar cover, L pair 1
4 M3x10 DIN 7985 Screw 6
*5 M8 DIN 6798 I Star washer 16
*6 M8x15 ISO 7380 Allen head bolt 13
7 213 4015 Handle grip 2
8 533 4059 Handlebar end cap 2
9 203 4039 Upright post welded, R 1
10 203 4041 Horizontal bar (incl. 116) 1
11 203 4040 Upright post welded, L 1
12 M8x55 ISO 7380 Allen head bolt 1
13 403 4115 Cable, set (incl. 13, 14, 98) 1
15 403 4099 Safety key 1
16 M5x10 DIN 7985 Screw 6
17 173 4067 Motor cover 1
18 M4x8 DIN 7985 Screw 2
21 403 4117 Micro switch (incl.19, 20, 22) 1
23 M4x8 DIN 7985 Screw 14
24 M5 DIN 127 Spring washer 2
25 403 4106 Sensor cable 1
26 813 4026 Motor 1,5 HP 1
27 503 4046 Motor bracket 1
28 M8x20 DIN 912 Head allen key bolt 2
29 403 4100x200 Circuit breaker 1
30 M8 DIN 934 Nut 1
31 M8x40 DIN 912 Head allen key bolt 3
32 653 4056 Screw 4
33 M6 DIN 137B Curve washer 2
34 343 4016 Lift motor shaft 1
35 813 4024 Lift motor (incl. 34,36-38) 1
37 653 4055 Nut (incl. 36) 1
38 2 DIN 11024 Pin 1
39 403 4110 Power board 1
40 403 4118 Capacitor 1
41 403 4121 Mains switch 1
42 403 4122 Mains cable socket 1
43 M4x6 DIN 7985 Phillips head screw 2
44 443 4017 Drive belt 1
45 443 4016 Running belt 1
46 523 4040 Rear roller 1
47 M8x30 DIN 912 Head allen key bolt 2
48 M8 DIN 137 B Curve washer 2
49 523 4039 Front roller 1
50 M6x25 DIN 7985 Screw 8
51 653 4054 Washer 8
52 433 4031 Running deck 1
53 433 4033 Anti-slip mat (incl. 106) 1
54 433 4032 Side landing (incl. 55) 2
56 503 4047 Deck bracket 2
57 M4x8 DIN 7985 Screw 4
58 533 4053 Rubber bumper 6
59 M8x50 ISO 7380 Screw 3
60 523 4041 Moving wheel sleeve 2
61 173 4068 Right rear end cap (incl. 62) 1
63 M4x15 DIN 7985 Screw 6
64 M8 DIN 985 Nylock nut 11
65 M8 DIN 9021 Washer 12
66 173 4069 Left rear end cap (incl. 67) 1
68 M6x10 DIN 7985 Screw 2
69 533 4063 Moving wheel 2
70 373 4008 Release lever (incl. 71-73) 1
74 223 4004 Cable, release (incl. 93, 94) 1
75 M8x65 DIN 912 Screw 2
76 M8x20 DIN 912 Head allen key bolt 6
78 503 4043 Incline support link br. (incl.77) 1
79 M8x30 DIN 912 Head allen key bolt 2
80 533 4066 Incline wheel 2
81 503 4044 Incline wheel bracket 1
82 103 4043 Incline structure frame 1
83 343 4013 Moving shaft 1
84 533 4067 Connection tube bushing 2
85 533 4068 Bushing spacer 2
86 533 4069 Track slider 2
87 343 4014 Fixed shaft 1
88 533 4070 Spacer 8
89 103 4044 H-frame 1
90 163 4006 Cas spring 2
91 M5x40 DIN 912 Screw 2
92 533 4071 Lock pin cap, L 1
95 533 4074 Frame end cap, R 1
96 533 4072 Snap bushing 3
97 103 4041 Main frame 1
99 533 4061 Base frame end cap 2
100 M6x15 DIN 7985 Screw 6
101 M6x40 DIN 912 Screw 2
102 533 4073 Track stopper 2
103 103 4042 Base frame 1
104 343 4015 Incline linkage shaft 1
105 533 4065 PVC foot 2
107 523 4044 Wheel sleeve 2
108 533 4064 Base frame end cap 2
109 533 4062 Base frame wheel 2
110 16 DIN 471 E-clip 2
111 813 4025 Choke 1
112 M3x6 DIN 7985 Screw 4
113 M3 DIN 127 Spring washer 4
114 403 4116 EMI fi lter (incl. 115) 1
116 213 4016 Handle grip horizontal 1
117 173 4076 Lower cover 1
118 233 4030 Membrane 1
* 403 4104 Power cable, EUR 1
* 423 4091 Lable set 1
* 553 4020 Assembly kit (incl *) 1
- 583 4028 Owner´s mamual 1
