3.2.7
LED Operation
Circuit Description
Table 4. Test Points
TP
DESCRIPTION
TP1
ADC common mode, input or output
depending on the setting of SW1, switch 4
TP3
THS4509 power down
TP4
ADC output enable
TP5
AGND
TP6
AGND
TP7
AGND
TP8
DGND
TP9
FPGA M0 pin; determines which FPGA logic
file to load
TP10
ADC SCLK
TP11
TPS75003 1.2 enable
TP12
TPS75003 2.5 enable
TP13
TPS75003 3.3 enable
To give greater visibility into the EVM operations, two LEDs are provided, D3 and D4. On power up, D4 is
asserted when a successful FPGA boot up is complete. For correct EVM operation, the LED should be
asserted at all times. LED D3 is asserted when the ADC and FPGA are operating and decoding in DDR
LVDS mode, and is not asserted when the ADC is functioning in CMOS mode. Furthermore, in either DDR
LVDS mode or CMOS mode, LED D3 blinks when an ADC overrange condition occurs.
CAUTION
If LED D3 is blinking, the amplitude coming into the ADC input (J3 or J4) must
be attenuated immediately; otherwise, damage to the ADC could occur.
