SECTION 6: KNOW YOUR LAWN TRACTOR
Figure 4
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
A Systems Indicator Monitor/Hour Meter G Throttle Control
B PTO (Blade Engage) Knob H Ignition Switch Module
C Choke Control I Brake Pedal
D Parking Brake Lever J Drive Pedal
E Shift Lever K Cruise Control Lever
F Cup Holder L Deck Lift Lever
SLOW
A
G
L
J
E
I
D
B
C
H
F
NOTE: Steering Wheel not shown for clarity.
K
