MIU202T Installation, Operation & Diagnostics Edition: December 28, 2000 Page 4
4. MODEM SPECIFICATIONS
Modulation: Bell202T
Modulation Type: FSK
Synch/Async:
Asynchronous Only
Data
Rate: 0 – 1200bps
Transmit
Frequency: Mark: 1200Hz
Space: 2200Hz
Error
Correction: None
Data Compression: None
Data Modulation Connectivity:
Using 16ms Polling Test
99.999% or better at -37dBm
99.5% or better at -40dBm
95% or better at -43dBm
Serial Formats and Flow Control:
Asynchronous and RTS/CTS flow control
Analog Interface
Tx Output Level: -0 dBm or -10 dBm *
Rx Sensitivity: -43dBm or -33dBm *
-43dBm for constant carrier
-40dBm for polling carrier
Line Termination: Dip Switch Selectable *
Line Impedance: 600 ohms balanced
2 or 4 Wire Configuration: Dip Switch Selectable *
