PCs
The following equipment must be installed on each PC that is to be
connected to the system:
With PS/2 Type Connectors:
M A VGA, SVGA or Multisync card.
M A 6-pin mini-DIN mouse port
M A 6-pin mini-DIN keyboard port
With AT Type Connectors:
M A VGA, SVGA or Multisync card.
M A DB-9 (standard serial), mouse port plus mouse adapter (part
# 2A-105).*
M A 5-pin DIN (standard AT), keyboard port plus keyboard adapt-
er (part # 2A-106).*
* Not included - requires separate purchase.
Cables
l Although it is possible to use standard extender cables to link
computers with PS/2 type keyboard and mouse ports to the
B013-000 Local, for optimum signal integrity and to simplify the
layout, we strongly recommend that you use the high quality CS
Custom KVM Cable that is provided with this package.
l It is not possible to use standard extender cables to link computers
with AT type keyboard and mouse ports to the B013-000 Local.
For those computers, using CS Custom KVM Cables must be used.
l Category 5 STP cable is required to connect the local and remote
B013-000 units. Using cable of a lesser standard will result in
degrading the video signal.
