Registers
General-Purpose Input/Output (GPIO) 20 SPRU724
5.5 Clear Data Register (CLR_DATA)
The GPIO clear data register (CLR_DATA) is shown in Figure 7 and described
in Table 7. CLR_DATA provides an alternate means of driving GPIO outputs
low. Writing a 1 to a bit of CLR_DATA clears the corresponding bit in
OUT_DATA. Writing a 0 has no effect. Reading CLR_DATA returns the
contents of OUT_DATA.
Figure 7. Clear Data Register (CLR_DATA)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8
CLR15 CLR14 CLR13 CLR12 CLR11 CLR10 CLR9 CLR8
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 3 2 1 0
CLR7 CLR6 CLR5 CLR4 CLR3 CLR2 CLR1 CLR0
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
Legend: R = Read only; R/W = Read/Write; -n = value after reset
Table 7. Clear Data Register (CLR_DATA) Field Descriptions
Bit Field Value Description
31−16 Reserved 0 Reserved. The reserved bit location is always read as 0. A value written to
this field has no effect.
15−0 CLRn Writing 1 clears the corresponding bit the OUT_DATA register. Reading this
register returns the contents of the OUT_DATA register. Writing a 0 has no
effect.
0 No effect
1 Clears the corresponding bit in OUT_DATA
