13 Model 161 Operating Procedures
Step 8
Lubricate the inside of the freezer door spouts from the
bottom. Insert the draw valves into the freezer door
from the bottom until the slot in the draw valves comes
into view.
Figure 11
Step 9
Slide the o-ring onto each pivot pin and lubricate.
Figure 12
Step 10
Slide the tip of the draw handle into the slot of the draw
valve, starting from the right. Slide the short pivot pin
through the far right draw handle. Slide the long pivot
pin through the far left and middle draw handles.
Figure 13
Step 11
Snap the design caps over the bottom of the freezer
door spouts.
Figure 14
Step 12
Lay the air tubes in the bottom of the mix hoppers.
