150Mbps High Power Wireless USB Adapter User Guide TL-WN7200ND
- 17 -
1) Enter a PIN from my Access Point
Choose the Config Mode as Registrar and enter the PIN of AP into the field under the Pin Code
as Figure 3-10 shown. And then click PIN button to start the wireless connection without doing
any configuration for AP.
Figure 3-10 QSS - Registrar mode
)
Note:
The default PIN code of the AP always can be found in its label or User Guide.
2) Enter the PIN into my Access Point
Choose the Config Mode as Enrollee and click the PIN button on the screen as Figure 3-11.
Meanwhile, enter the PIN code of the adapter into the configuration utility of the AP. For the
detailed instructions of the AP configuration, please refer to the User Guide of the AP.
Figure 3-11 QSS - enrollee mode
)
Note:
The PIN code of the adapter is displayed on the QSS configuration screen as Figure 3-11 (the
default PIN code for this adapter is 08781949 as Figure 3-11 shown).
