150Mbps High Power Wireless USB Adapter User Guide TL-WN7200ND
- 16 -
)
Note:
To build a successful connection by QSS, you should also do the corresponding configuration of
the Access Point for QSS or WPS function meanwhile.
I. PBC Method
If your Access Point is equipped with a push-button for Wi-Fi Protected Setup, you can connect
the adapter to the Access Point by Push QSS Button method.
Step 1 Press the QSS button on your Access Point device.
Step 2 Click the QSS button (marked by the red circle) on the screen as Figure 3-9.
Figure 3-9 QSS- QSS BUTTON mode
Or: Press and hold the QSS button on the adapter (shown on the following figure) for 2 or 3
seconds.
II. PIN Method
If your Access Point supports Wi-Fi Protected Setup and the PIN method, you can add the
adapter to the network by the following two ways:
