BRIGHTNESS:
Adjusts background black level of the screen image
CONTRAST:
Adjusts foreground white level of the screen image
H. POSITION:
Moves the screen image left or right
V. POSITION:
Moves the screen image up or down
PITCH:
Adjusts image distortion appearing as vertical bars or
“noise” on the screen
PHASE:
Adjusts image distortion appearing as horizontal bars or
“noise” on the screen
SHARPNESS:
Adjusts the clarity and focus of the screen image
COLOR METER:
Adjusts color temperature
LANGUAGE:
Allows you to choose from English, French, German,
Italian, or Spanish
AUDIO CONTROL:
Switch muting ON/OFF and controls volume
INPUT SELECTION:
Selects VGA, VIDEO, S-VIDEO signal inputs
RECALL:
Returns all controls back to default settings
HOT KEY CONTROL
1. VGA HOT KEY
UP KEY > BRIGHTNESS
DOWN KEY > CONTRAST
2. VGA + HOT KEY
UP KEY > VOLUME INCREASE
DOWN KEY > VOLUME DECREASE
