Model – Tatung TLM-1703 User Manual
Page 11
DISPLAY MODES
Model
Resolution
H Freq (kHz)
V Freq (kHz)
0
720 x 350
31.469
70.087
1
640 x 480
31.469
59.940
2
640 x 480
35.000
66.667
3
640 x 480
37.861
72.809
4
640 x 480
37.500
75.000
5
720 x 400
31.469
70.087
6
800 x 600
35.156
56.250
7
800 x 600
37.879
60.317
8
800 x 600
48.077
72.188
9
800 x 600
46.875
75.000
10
832 x 624
49.750
74.500
11
1024 x 768
48.363
60.004
12
1024 x 768
56.476
70.069
13
1024 x 768
58.038
71.918
14
1024 x 768
60.023
75.029
*15
1280 x 1024
64.000
60.000
*16
1280 x 1024
80.000
75.000
Note: *Only 17” can support up to 1280x1024
SERVICE INFORMATION
If you experience problems with this product, please contact us at (800) 829-2850
or (310) 637-2105 and ask for:
Gale Kroth, Service Rep ext. 242
Larry Chen, Service manager, ext. 216
Page 10
