TPA311 MSOP Audio Power Amplifier Evaluation Module Parts List
3-14
Details
3.5
TPA311 MSOP Audio Power Amplifier Evaluation Module Parts List
Table 3–1. TPA311 MSOP EVM Parts List
Ref.
Description
Size
EVM
Qty.
Manufacturer/
Part Number
Vendor Number
C5
Capacitor, 10
µ
F, 6.3 V
A
1
Panasonic
ECS-TOJY106R
Digi-Key
PCS1106CT-ND
C1, C2,
C3
Capacitor, 1
µ
F,
+80%/–20%, nonpolarized
0603
1
Murata
GRM39-Y5V105Z10PT
C4
Capacitor, 5 pF
0603
1
Panasonic
ECU-V1H050CCV
Digi-Key
PCC050CVCT-ND
R1, R2,
R4
Resistor, 20 k
Ω
, 1/16 W, 5%
0603
3
Panasonic
ERJ-3GSYJ203
Digi-Key
P20KGCT-ND
R3
Resistor, 39 k
Ω
, 1/16 W, 5%
0603
1
Panasonic
ERJ-3GSYJ393
Digi-Key
P39KGCT-ND
S1
Switch, momentary
1
Panasonic
P8048SCT-ND
Digi-Key
P8048SCT-ND
Terminal Post Headers
9
Sullins
PTC36SABN
Digi-Key
S1022-36-ND
U1
IC, TPA311DGN
†
, audio
amplifier, 350 mW, mono
MSOP-8
1
TI
TPA311
PCB1
PCB, TPA311 MSOP EVM
1
† Due to the very small size of the MSOP IC package, the standard part number TPA311 is replaced with the code TIAAB
Note:
All items are SMD except as noted.
