2.2 System
Diagram
The following diagram shows the SpectraLink components residing on a network with
the Mitel Networks IP telephony system, access points (APs), and wireless LAN Ethernet
Switched Hub:
(Mitel Networks IP telephony server architecture example)
SVP Server
Ethernet switch
Access Point
Wireless
POS
Wireless
Telephones
Access Point
Mitel IP
Phones
optional
Mitel IP system
PSTN
or
PBX
Device supplied by
SpectraLink
Ethernet cable
Phone cable
TFTP Server
Wireless
Telephones
