Page 7: Chapter 2 - hard drive

Taurus S2 User Guide
Your unit may come
with a pre-installed
hard drive. Before
opening such an
enclosure, please
read the warranty
from your vendor
carefully, as this
could void your
warranty.
The aluminium
ved
stand does not
have to be remo
for drive assembly.
For RAID 0 and
RAID 1, drives with
s
identical capacitie
are recommended.
Do not bend the
thermal sensor!
Assembly
1. Remove the four screws at the bottom of the case.
Chapter 2 - Hard Drive
2. Push the inner enclosure out, and remove the outer chassis.
3. Install the first hard drive and mount it with two screws on
each side.
4. Attach the thermal probe with the tape provided to the first
HDD. Choose a place in between the two drives but without
damaging the probe when installing the second drive.
Page 5 / Chapter 2 - HDD Assembly
