2-1
Quick Start
Quick Start
Follow the steps in this chapter to quickly prepare the TPA032D03 mono
class-D audio amplifier EVM for use. Using the TPA032D03 class-D EVM with
the TI plug-n-play audio amplifier evaluation platform is a quick and easy way
to connect power, signal and control inputs, and signal outputs to the EVM
using standard connectors. However, the audio amplifier evaluation module
can be used stand-alone by making connections directly to the module pins,
and it can be wired directly into existing circuits or equipment.
The platform switch and jumper settings shown in Table 2–1 are typical for the
TPA032D03 class-D EVM. There are no jumpers or switches to set on
the TPA032D03 class-D EVM board, itself.
Table 2–1. Typical TI Plug-N-Play Platform Jumper and Switch Settings for the
TPA032D03 Class-D EVM
POWER TYPE (Note 2)
JP1
JP2
JP3
JP4
JP5
JP6
JP7
JP8
S1
S2 (Note 3)
S3
VCC (J1)
ON
OFF
OFF
ON
ON
Mute
X
Lo
ON
OFF
U5
AC/DC (J2)
OFF
ON
OFF
ON
ON
Mute
X
Lo
ON
OFF
U5
Notes:
1) ON = Jumper installed, OFF = Jumper
NOT Installed, X = Don’t care
2) Install a voltage regulator EVM (SLVP097) in platform socket U6 for VDD power to EVM control inputs.
3) Set to ON when Tone Control Board SLOP109 is installed in U1, otherwise set to OFF.
Topic
Page
2.1
Precautions
2–2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2
Quick Start List for Platform
2–3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3
Quick Start List for Stand-Alone
2–5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2
