Controls (continued)
13
A. Parking Brake Lever
Locks brake. Set parking brake when
unit is not in use. See page 19 for
operating instructions.
B. Brake / Neutral Pedal
Stops forward or reverse movement
of the tractor. See page 19.
C. Choke Lever
When activated, the choke restricts
amount of air mixing with fuel.
Activate choke when starting a cold
engine. Once engine is started, move
lever slowly to "OFF". See “Starting
Engine” on page 16 for instructions.
D. Cruise Control Switch
(13074 & 13076)
The cruise control allows the
operator to maintain a constant drive
speed without contacting the travel
pedal. When activated, the cruise
control sets the travel pedal at the
desired position. See page 19 for
instructions.
E. Light Switch
Activates headlights.
F. Auxiliary Hydraulic Lever
(Model 13076)
Activates the auxiliary hydraulics.
See page 17 for instructions.
G. Attachment Lift Lever
Controls the hydraulic attachment lift.
See page 17.
H. Hour Meter
Registers hours of tractor use.
J. Fuel Gauge (13074 & 13076)
Indicates the amount of fuel in the
fuel tank.
K. Attachment/PTO Drive Switch
Engages and disengages power to
attachments.
L. Throttle
Controls engine speed. Always
operate engine at full throttle
when operating attachments. See
page 16 for instructions.
M. Travel Pedal
Controls forward and rearward
movement of tractor. See page 18.
N. Ignition / Starter Switch
Starts engine. See page 16 for
engine starting instructions.
O. Cruise Control Light
(13074 & 13076)
Indicates when cruise control is on.
P. Oil Pressure Light
(13074 & 13076)
IF LIGHT IS ON, STOP ENGINE
IMMEDIATELY. When lit, indicates a
lack of oil pressure in the engine.
Engine damage may result. Service
before re-starting.
Q. Start Light
Indicates when ignition switch is in
the start position and safety start
interlock switches are not activated.
R. Battery Light
When lit, indicates low battery
voltage.
S. Attachment/PTO Drive Light
When lit, indicates attachment/PTO
drive is activated.
T. Two-Speed Transmission
Lever (Model 13076)
Lever is located under seat, on the
left side. Shifts transmission into low
range or high range. See
“Hydrostatic Transmission” on page
18.
Z. Seat Adjustment Lever
(13074 & 13076)
Locks and releases seat for
adjustment. Lift lever to slide seat
forward or backward. See page 19.
Identification and Function of Controls and Features
Before operating this tractor, become familiar with the function and location of each control. This will help ensure proper, safe and
efficient operation. See the “Operation” section for instructions.
