Model LLG & LLD Pool and Spa Heater
Page 21
Description
Part Number
13.
Bracket, Insulation Retainer ...................................... 10462200
14.
Sleeve, Temperature Control Bulb ............................ 10444900
15.
Retainer Bracket ....................................................... 10447300
16.
Wire Harness, High Limit ......................................... 10419300
17.
Disc, High Limit 150°F
(see Note 1) ........................ R0023000
18.
Disc, High Limit 135°F
(see Note 1) ........................ R0022700
19.
Connector Fitting ..................................................... P0019700
20.
Plug 3/4 NPT ........................................................... P0027000
21.
Plug 1/4 NPT ........................................................... P0026800
*E. BURNER TRAY ASSEMBLY (LLD)
Burner Tray Assembly, Nat ....................................... R0316901-05
Burner Tray Assembly, LP ....................................... R0319501-05
1.
Burner Tray Weldment ....................................... R0317001-05
2.
Burner ...................................................................... L0052300
3.
Gas Valve, Nat ........................................................ R0317100
3.
Gas Valve, LP ......................................................... R0319600
**E. BURNER TRAY ASSEMBLY (LLG)
Burner Tray Assembly, Nat ....................................... R0098601-05
Burner Tray Assembly, LP ........................................ R0098701-05
1.
Burner Tray Weldment ....................................... R0099501-05
2.
Burner ...................................................................... L0052300
3.
Gas Valve, LP ......................................................... R0096900
3.
Gas Valve, Nat ........................................................ R0096400
4.
Pilot Main Burner Assy LP ....................................... R0099200
4.
Pilot Main Burner AssyNat ....................................... R0099100
5.
Pilot, Burner, LP, .010 ............................................. R0096600
5.
Pilot, Burner,Nat, .018 ............................................. R0096700
6.
Pilot Generator ....................................................... W0036901
7.
Ceramic Insulator Assy ........................................... R0099300
8.
High Voltage Lead Assy .......................................... R0098900
9.
Pilot Tube ................................................................ R0096300
10.
Piezo Lighter Assy ................................................... R0096800
F. TEMPERATURE CONTROL ASSEMBLY
**1.
Temperature Control (LLG) ..................................... R0058200
2.
Knob, Thermostat .................................................... R0313800
*1.
Temperature Control (LLD) ...................................... R0011700
2.
Knob, Thermostat .................................................... R0313800
OPTIONAL EQUIPMENT
Non Combustible Base ................................................ 10512701-05
Pressure Relief Valve, 3/4NPT, 75 PSI ............................ A0063300
1. Items 17 & 18 available as Assembly R00232.
NOTE:
*-LLD (Direct Ignition)
**-LLG (Standing Pilot)
