Hi-Res. B/W camera instruction manual
ADC 660N and ADC 660P
_________________________________
19
IV. SPECIFICATIONS
MODEL ADC660N ADC660P
TV SYSTEM EIA CCIR
EFFECTIVE PIXELS 768(H) X 494(V) 752(H) X 582(V)
IMAGE DEVICE 1/3” INTERLINE TRANSFER CCD
SCANNING SYSTEM 2:1 INTERLACE
SYNCHRONIZING SYSTEM INTERNAL/LINE LOCK SELECTABLE
HORIZONTAL RESOLUTION 580 TV LINE
VIDEO OUTPUT LEVEL 1 V pp/75 ohm
S/N RATIO MORE THAN 50 dB (AGC OFF)
MIN.ILLUMINATION (F1.2) 0.03 lux
ELECTRONIC IRIS 1/60 ~ 1/100,000 SEC 1/50 ~ 1/100,000 SEC
LINE LOCK RANGE 60 Hz ± 1 Hz 50 Hz ± 1 Hz
BACKLIGHT COMPENSATION
ON/OFF SELECTABLE (CENTER ZONE WEIGHTED)
BACKFOCUS ADJUSTMENT FINE ADJUSTMENT WITH SELF LOCKING SYSTEM
CAMERA MOUNT 1/4-20 UNC (TOP or BOTTOM SELECTABLE)
LENS MOUNT C- or CS-MOUNT (C-MOUNT ADAPTOR RING INCLUDED)
AUTO IRIS SUPPORT
VIDEO-DRIVE TYPE WITH 3P TERMINAL
DC-DRIVE TYPE WITH 4P SQUARE CONNECTOR
POWER REQUIREMENT 12V DC ± 20% 200mA MAX/24V AC ± 20% 100mA MAX
OPERATION CONDITION 14° F TO 122° F (-10℃~50℃) WITHIN 85% RELATIVE HUMIDITY
NET WEIGHT
(WITHOUT LENS)
APPROX. 0.9 lb (400 g)
DIMENSIONS (W x H x L) 2.2 in. x 2.2 in. x 5.55 in. (55 x 55 x 141 mm)
