Trion Air Boss ATS - Manual (Page 12)

8
DIM. “A”
DIM. “B”
DIM. “D” DIM. “C”
4.00 RAIL
26.75 42.50 28.75 28.75 12.00 DIM. “F”
DIM. “E”
BI
UPBLAST
FAN
TRANSITION
IMPINGER
MODULE
(DOOR SWING
22 1/8”)
ELECTROSTATIC AIR
CLEANER MODULE
(DOOR SWING 38 3/8”)
MEDIA FILTER
MODULE
(DOOR SWING
24 5/8”)
MEDIA FILTER
MODULE
(DOOR SWING
24 5/8”)
AVG. WATER
MODULE MODULE INSIDE INSIDE SYSTEM BLOWER MODULE SYSTEM REQUIRED CELL FACE DETERGENT
SYSTEM MODULE SP @ WIDTH FLANGE ID UNIT HEIGHT FLANGE ID DEPTH DEPTH WEIGHT WEIGHT CPM/WASH AREA PER CYCLE
(CFM) DESIGNATION RATED CFM DIM. “A” DIM. “B” DIM. “C” DIM “D” DIM “E” DIM “F” (LBS) (LBS) @50 PSI (FT2) (GAL)
ATS-2 IMPINGER 1.33" 27.96 24.25 34.25 27.19 174.25 35.00 175 1330 4.0 3.68 .20
1,375 ELECTROSTATIC 0.39" 320 4.0
TO MEDIA 0.44" 115 --
2,000 ADSORBER 0.25" 315 --
BLOWER -- 270 --
(TOTAL SP 2.41")
ATS-4 IMPINGER 1.33" 50.00 46.38 34.25 27.19 176.25 37.00 235 2050 9.3 7.37 .40
2,750 ELECTROSTATIC 0.39" TO TO 480 9.3
TO MEDIA 0.44" 183.25 44.00 150 --
4,000 ADSORBER 0.25" 550 --
BLOWER -- 420 --
(TOTAL SP 2.41")
ATS-6 IMPINGER 1.33" 72.38 68.75 34.25 27.19 179.25 40.00 295 2700 14.6 11.06 .63
4,125 ELECTROSTATIC 0.39" TO TO 640 14.6
TO MEDIA 0.44" 186.75 47.50 185 --
6,000 ADSORBER 0.25" 785 --
BLOWER -- 535 --
(TOTAL SP 2.41")
ATS-8 IMPINGER 1.33" 50.00 46.38 58.63 51.56 186.75 47.50 390 3400 18.6 14.74 .91
5,500 ELECTROSTATIC 0.39" TO TO 780 18.6
TO MEDIA 0.44" 190.25 51.00 270 --
8,000 ADSORBER 0.25" 1070 --
BLOWER -- 675 --
(TOTAL SP 2.41")
ATS-10 IMPINGER 1.33" 61.18 57.56 58.63 51.56 190.25 51.00 460 3900 24.0 18.45 1.20
6,890 ELECTROSTATIC 0.39" TO TO 893 24.0
TO MEDIA 0.44" 193.25 54.00 305 --
10,000 ADSORBER 0.25" 1297 --
BLOWER -- 770 --
(TOTAL SP 2.41")
ATS-12 IMPINGER 1.33" 72.38 68.75 58.63 51.56 190.75 51.50 520 4450 29.3 22.12 1.40
8,250 ELECTROSTATIC 0.39" TO TO 1010 29.3
TO MEDIA 0.44" 198.25 59.00 345 --
12,000 ADSORBER 0.25" 1545 --
BLOWER -- 870 --
(TOTAL SP 2.41")
(1) DIMENSIONS SHOWN IN INCHES
(2) SYSTEM DEPTH AS SHOWN TO THE SUM OF ALL MODULE, TRANSITION & FAN DEPTHS AND 1/8” GASKET ALLOWANCE BETWEEN EACH MODULE.
(3) SYSTEM WEIGHT EQUAL TO THE SUM OF ALL MODULE WEIGHTS AND MOUNTING RAIL.
(4) IMPINGER MODULE AND ELECTROSTATIC MODULE SUPPLIED WITH (2) 1” WASH WATER SUPPLY COUPINGS AND (1) 2” DRAIN COUPLING.
(5) MODULE ACCESS DOORS LOCATED ON ONE SIDE. (LIFT-OFF HINGES) SPECIFY ACCESS REQUIRED.
