TPA311 Audio Power Amplifier Evaluation Module Parts List
3-14 Details
3.5 TPA311 Audio Power Amplifier Evaluation Module Parts List
Table 3–1. TPA311 EVM Parts List
Ref. Description Size
EVM
Qty.
Manufacturer/
Part Number
Vendor Number
R4 Trim Pot, 200 k
Ω
Cermet
ST SL, (through hole)
1 Bourns
3323P-1-204 Digi-Key
3323P-204-ND
C5 Capacitor, 10
µ
F, 6.3 V A 1 Panasonic
ECS-TOJY106R Digi-Key
PCS1106CT-ND
C1 Capacitor, 1
µ
F,
+80%/–20%, nonpolarized
1206 1 Murata
GRM42-6Y5V105Z16BL Newark
93F2254
C2, C3 Capacitor, 2.2
µ
F, 20%,
nonpolarized
1206 2 TDK
C3216X5R1A225
C4 Capacitor, 5 pF 0805 1 Panasonic
ECU-V1H050CCN Digi-Key
PCC050CNCT-ND
R1, R2,
R3 Resistor, 20 k
Ω
, 1/8 W, 5% 1206 3 Panasonic
ERJ-8GEYJ203 Digi-Key
P20KECT-ND
S1 Switch, momentary 1 Panasonic
P8048SCT-ND Digi-Key
P8048SCT-ND
U1 IC, TPA311, audio
amplifier, 350 mW, mono SOIC-8 1 TI
TPA311
PCB1 PCB, TPA311 sample EVM 1
Note: All items are SMD except as noted.
