Troy-Bilt Transmatic Lawn Tractor 77T - Manual (Page 43)

43
10
Illustrated
Parts List
Ref.
No.
Part No. Description
1 683-04256 Muffler Shield Assembly
2 783-04576 Muffler Shield
3 783-05006 Lower Heat Shield
4 710-0227 Screw, #8-18 x .50
5 710-0599 Screw, 1/4-20, 0.500
6 710-0642 Screw, 1/4-20, 0.750
7 710-1237 Screw, #10-32, .625
8 710-1314A Socket Cap Screw, 5/16-18, .625
9 710-1315 Self-tapping Screw, 3/8-16, 1.25
10 712-0271 Hex Sems Nut, 1/4-20
11 721-0208 Exhaust Gasket
12 725-0157 Cable Tie, 7.4”
13 726-0205 Hose Clamp, .490
14 728-04000 Pop Rivet .188 x .325
15 731-1682A Oil Drain Sleeve
16 751B221535 Casing Clamp
17 751-0564B Muffler Deflector
18 751-10013 Exhaust Pipe
19 751-10162 Muffler, Single Inlet
20 751-10349 Fuel Line Hose
21 751-10353 Long Muffler Deflector
22 783-04573 LH Muffler Bracket
23 783-04574 RH Muffler Bracket
For parts and/or
accessories
please call
1-866-840-6483, or
1-330-558-7220.
www.troybilt.com
