Troy-Bilt Transmatic Lawn Tractor 77T - Manual (Page 31)

31
10
Illustrated
Parts List
Ref.
No.
Part No. Description
1 710-04483 Screw, 1/4-20 x .500
2 710-0599 Screw, 1/4-20, 0.500
3 710-0604A Screw, 5/16-18, 0.625
4 731-04591A Cup Holder
5 736-0607 Lock Washer, 5/16
6 783-04587A Fender
7 783-1489B Mounting Bracket, Seat
8 723-04025 Foot Pad, Abrasive, RH
9 723-04026 Foot Pad, Abrasive, LH
10 712-04063 Nut, Flange Lock, 5/16-18, GrF
11 720-04061 Knob, 3/8-16, .875
12 732-1184 Spring, Exten., .84 Dia x 4.6 Lg.
13 738-0296 Scr., Shlder, .437 x .268, 5/16-18
14 738-04012A Screw, Shlder, .625 x .175, 3/8-16
15 783-04081A Pivot Bracket, Seat
16 783-0209D Lift Bracket, Seat
17 757-04021A Seat, Low, Black
18 710-0227 Screw, #8-18 x .50
19 726-0279 Plate, Insulator
20 725-1303 Spring Switch, Outer
21 725-1439 Spring Switch, Inner
22 726-0278 Plate, Insulator Boss
For parts and/or
accessories
please call
1-866-840-6483, or
1-330-558-7220.
www.troybilt.com
