3. Operation

Note: To switch between computers, you can use the front-panel push buttons
or the Hot Key commands.

LED Indicators

Red LED light: KVM cable is
connected and PC is powering the
KVM switch.

Green LED light: Indicates the
selected PC port is active, whether
the computer is turned on or off.

Hot-Key Commands
A keyboard hot-key command consists of three keystrokes:

Hot-Key command = ScrLk + ScrLk + Command key(s)

After pressing the ScrLk key, you have 2 seconds to press the ScrLk key again.
You then have another 2 seconds to press a command key. If you do not press
a key within 2 seconds, the switch will exit hot-key mode.

To select a specific PC port:

For a list of all the Hot-Key commands, please see the Quick Reference Sheet.

ScrLk

ScrLk

X

+

+

x = 1~4 for PC channel number

Select PC =

Push Buttons
Press the push buttons to switch
between computers.
