S p e c i f i c a t i o n s
P h a s e r ® 5 6 0
Phaser 560 Phaser 560EF
Colour Technology Colour Laser Colour Laser
Resolution 600 x 600 dpi 600 x 600 dpi, 1200 x 1200 dpi
Engine print speed Colour Monochrome Colour Monochrome
Fast Color 4.7 ppm - 4.7 ppm -
Standard 3.5 ppm 14 ppm 3.5 ppm 14 ppm
Premium - - 1.8 ppm 7 ppm
Transparency 1.5 ppm 7 ppm 1.5 ppm 7 ppm
Fast Monochrome - 14 ppm - 14 ppm
Media handling
Standard sizes:
A4, US Letter, US Legal (with 24MB)
Types: Common office papers & Transparencies
Weights: 60-106 gsm from tray, 75-165 gsm from multi-purpose tray
Multi-purpose tray: 100 sheets paper or envelopes, labels, cardstock, fabric transfer, coated paper
& transparency. Capacity: 100 sheets (paper), 50 sheets (transparencies)
Optional 2nd feeder: Extra 500 sheets paper from 2 trays
Output tray: Capacity: 500 sheets
Image Area 200 mm x 287 mm (A4), 208 mm x 269 mm (US Letter), 208 mm x 343 mm (US Legal)
Duplex Printing Tray fed Tray fed
Job Pipelining - Yes
Checkpoint Preview - Yes
Print Collation - Yes
Copystation support Yes with 24 MB Yes
Memory 8 MB expandable to 72 MB 40 MB expandable to 72 MB
Network interfaces Bi-directional parallel port, SCSI port for Phaser Copystation or collation/font disk.
(Standard):
(Optional
Ethernet (EtherTalk, Novell Netware and TCP/IP), TokenRing (Novell Netware,
PhaserShare cards): TokenTalk and TCP/IP), LocalTalk, Serial.
Printer Language Adobe PostScript™ Level 2, HP-GL™, PCL ® 5 mono, Automatic language
Support sensing and switching
Controller 33-MHz AMD 29040 RISC processor with memory compression co-processor and
proprietary image processing for accelerated throughput
Colour Management TekColor-Vivid Color, SWOP, SNAP, Commercial, EuroScale, PANTONE,
and Profiles Adobe PostScript™ Level 2 device-independant colour, CIE international colour
standards and support for ICM and Apple ColorSync colour management
Printer drivers Windows 95, 3.x, NT, OS/2 and Macintosh (includes QuickDraw GX)
(Standard) PhaserPrint plug-in for Adobe Photoshop (Macintosh version)
(Optional) PhaserPrint for Unix workstations - SUN, SGI, HP, IBM and DEC
Resident fonts 17 39
Warranty 1 year on-site warranty Extended warranty options available
Physical Height: 454 mm* * 666 mm with lower tray assembly
specifications Width: 507 mm** ** 782 mm with output tray
Depth: 492 mm
Weight: 53.3 kg
Lower Tray
Assembly
Weight: 14 kg
UK International Distribution
Tel: 01628 403600 Tel: +44 1628 403627
Fax: 01628 403617 Fax: +44 1628 403618
560DS-02EA
Fast output on all office papers. The powerful
33MHz RISC processor will speed through the largest, most
complex job - nearly 5ppm in colour and 14ppm in black and
white. It’s quick when it comes to printing on a range of media
from the new multi-purpose feeder, including address
labels, envelopes: while vivid colour overhead
presentation slides can be produced in moments.
Brilliant photographic quality. 1200 x 1200dpi
gives superb, fine-detail full-
colour printing on any plain
paper - excellent for
printing documents with scanned
artwork or photographs.
TekColor Automatic Color
Correction.
New feature of the Phaser
560 - automatically selects the best colour
correction and print mode according to the content of
the page being printed.
Lower cost colour printing you won’t believe.
Colour printing in-house saves the cost of out-sourcing to a bureau and
allows quick, last minute changes. The Phaser 560 has high
capacity consumables and delivers low cost per copy (even lower
than inkjets) plus it has the highest number of prints between
refills of any desktop colour laser printer.
Easy to use for all office users, with built-in colour settings
for superb quality on different papers. And it’s made for the
workgroup; “Plug & Play” with Windows 95 and compatible
with all major networks, with built-in Adobe PostScript ™ Level 2,
the industry leading standard, to avoid application and driver problems.
A range of applications . The Phaser 560 provides high
speed, on-demand colour printing for every office,
including A4-size colour and black and white
documents, presentation visuals and colour
handouts. High quality, accurate reproduction is
perfect for data analysis or you can produce
cost-effective, high quality short print-runs of
leaflets, brochures and adverts.
A breakthrough in printer
management.
Platform-independent
Tektronix PhaserLink ™ provides user and management information from the
Phaser 560 to any desktop in your company, using any standard web browser.
Easy to use, it helps reduce costs and
offers 24 hour support via the Internet.
Phaser 560 productivity features include
Job Accounting, which enables charging
on a usage basis: CheckPrint to allow
checking of the first page of a multipage
job before continuing, avoiding wasted
time and consumbles: and Job Collation,
allowing the printer itself to collate a multicopy, multipage job,
rather than tying up the host computer.
Make it a colour copier with the Tektronix Copystation (requires
min 24Mb RAM). Copy originals and enlarge up to 8.5 x 14” (216 x 355mm)
in glorious colour (or grey scale or black and white) as easily as your
photocopier. And it’s fast - nearly 5ppm in colour or 14ppm mono.
TekColor Care. Outstanding support and service are our culture. Technical
support is available anytime via the World Wide Web and through our Highly
Automated fax Library (HAL) and our electronic bulletin board. Or call our
European Service Centre during business hours. Beyond our standard
one-year warranty, we offer a range of extended service plans for extra
peace of mind.
