MODEL 22610709 - 12 TORO Z-MASTER 2001
PECO
PECO
PECO
PECO
PECO
PECO
PARTS LIST
REF. NO. PART NO. DESCRIPTION QTY.
1 *******
BOOT PLATE (SPECIFY DECK SIZE)
1
2 *******
BOOT (SPECIFY DECK SIZE)
1
3 J6006
7"- 8" HOSE CLAMPS
2
4 *******
7" x 48" LOWER HOSE
1
5 E6004
7" BLOWER CONE
1
6 *******
ENGINE/BLOWER/BLADE ASSEMBLY
1
E4052A
BLOWER HOUSING
D4002
5HP BRIGGS & STRATTON ENGINE
A0645
4 BLADE IMPELLAR W/ S4311 BUSHING
W/ 3/4" SHAFT
D1016
6HP KOHLER ENGINE
A0914
4 BLADE IMPELLAR W/ S4302 BUSHING
W/ 1" SHAFT
7 J6011
5"- 6" HOSE CLAMPS
2
8 *******
6" x 36" LOWER HOSE
1
9 V1054
UPPER INLET
1
10 A0023
HARDTOP ASSEMBLY
1
11 A0913
BASE FRAME ASSY
1
12 A0907
(OPTIONAL) WEIGHT ASSEMBLY
1
13 B2250
CHANNEL CLAMP
1
14 A0917
MOUNT PLATE ASSEMBLY
1
16 A0780
ENGINE MOUNT ASSEMBLY
1
17 B1941
INSIDE INLET PLATE
1
18 B1926
OUTSIDE RETAINING PLATE
1
19 J0316
GAS STRUT
2
20 A0021 RIGHT HAND HINGE PLATE ASSEMBLY 1
21 A0022
LEFT HAND HINGE PLATE ASSEMBLY
1
22 A0236
LATCH ASSEMBLY
2
23 A08221
HARDWARE BAG
1
24
VV2002
PLASTIC CONTAINERS 7 CU. FT.
1
6
