Controls - F792 Switchbox LP Series
Typical Description – Electrical Switches
F792 LSB LP WP 2SPDT 240VAC
Figure No. Limit Switchbox Type Enclosure Rating Switch Type Voltage
(Low Profile) (weatherproof)
Typical Description – Proximity Sensors/Switches
F792 LSB LP WP Prox NO PNP
Figure No. Limit Switchbox Type Enclosure Rating Proximity Action Switch Style
(Low Profile) (weatherproof) Normally Open
Typical Description – Pneumatic Switches
F792 LSB LP WP Pneu NNP
Figure No. Limit Switchbox Type Enclosure Rating Pneumatic Action
(Low Profile) (weatherproof) Switch Normally Non Passing
Selection Guide
EDP Description Part No. Comments
F792 LSB LP WP 2SPDT 20-260VAC 422987 Weatherproof type with two 240 VAC electrical switches
F792 LSB LP WP PROX NAMUR 169555 Weatherproof type with two 8 VDC proximity sensors
F792 LSB LP WP PROX NO PNP 642884 Weatherproof type with two 10-30 VDC proximity switches
F792 LSB LP WP PROX NC PNP 764321 Weatherproof type with two 24 VDC proximity switches
F792 LSB LP WP PROX NO NPN 768482 Weatherproof type with two 24 VDC proximity switches
F792 LSB LP WP PROX NC NPN 252866 Weatherproof type with two 24 VDC proximity switches
F792 LSB LP WP PROX AC 116538 Weatherproof type with two 20-260 VAC proximity switches
F792 LSB LP WP 2 PNEU NNP 812791 Weatherproof type with two pneumatic switches
Note:
SPDT = Single Pole Double Throw
NO = Normally Open
NC = Normally Closed
NNP = Normally Non Passing
