Controls - F792 Switchbox LP Series
Microswitch Specifications
Voltage
Resistive load
Tungsten lamp load (amps)
Inductive load
(Volts)
(Amps)
NC
NO
(Amps)
AC
125
10
2
1
10
250
10
1.5
1
10
DC
Up to 15
15
3
1.5
15
30
10
3
1.5
10
50
3
0.8
0.8
2.5
75
1
0.6
0.6
0.5
125
0.5
0.5
0.5
0.07
250
0.25
0.25
0.25
0.03
Proximity Sensor Specifications – 2 & 3 Wire Specification
Proximity Sensor- 2 wire specification
Type:
Pepperl & Fuchs NJ2-V3-N or equivalent
Sensing Distance:
2mm maximum (metal face). NB separate amplifier
required
Supply:
8V DC (Ri approx. 1k0hm)
Output:
•
Sensor absent - 3mA or above
•
Sensor present - 1mA or below
Proximity Switch - 3 wire specification
Type:
Bailiff BES 5173
Supply Voltage:
10-30VDC
Current:
≤
200mA
Frequency:
≤
1500Hz
Pneumatic Switch Specifications
Signal connections:
4mm O.D. tube.
Switch details:
•
Telemecanique PXC–M111 or equivalent
•
2 switches per box
•
Switches normally non passing (NNP)
•
Capacity – 60 L/min at 550 kPa to atmosphere
•
pressure range 300 – 800 kPa
Temperature range:
Minus 15°C to 60°C
