Control Up to 8 PCs from a Single Console (Keyboard, Monitor and Mouse) •
No Software Required - PC Selection done via Front Panel Switches or Hot Keys •
Quick View Scan Mode for Monitoring Selected PCs •
PS/2 and Serial Mouse Emulation Provided for System Bootup •
Console’s PS/2 Mouse Controls All Connected PCs •
Microsoft Intellimouse Pro, Logitech FirstMouse, FirstMouse+ Support* •
SVGA, VGA and Multisync Monitor Support •
LED Display for Easy Status Monitoring •
Rack Mountable in 19” System Rack •
Hot Pluggable - Add or Remove PCs for Maintenance Without Powering Down the Switch •
Superior Video Quality: 1920x1440; DDC2B. •
* 1. PS/2 compatible mouse support is for three button (wheel) mice.
2. The Change Device procedure in the Logitech Mouse Ware program does not work in Microsoft NT.
Features
Hardware Requirements
A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be •
using on any of the PCs.
A PS/2 Style Mouse
•
A PS/2 Style Keyboard •
Each PC must have:
A VGA, SVGA, Multisync card or USB port.* •
A 6-pin mini-DIN (PS/2 style). •
Either a 6-pin mini-DIN (PS/2 Style) keyboard port or a USB port.* •
The following are the cables needed to connect your KVM Switch to the CPUs:
P750-006 PS/2 Cable Kit – 6’
P750-010 PS/2 Cable Kit – 10’
P750-015 PS/2 Cable Kit – 15’
NOTE: The wiring and pin assignments will not let you use a Serial-to-PS/2 adapter at the KVM side of the cable.
Attempting to use a standard serial extender cable with adapters at both ends will fail.
* Use a B015-000 PS/2 to USB Adapter to connect a USB computer to the KVM (still requires a P750 series cable kit to
complete CPU connection).
Console
PC
Cables
