ASSEMBLY
Assembly Section 2-16
SOLENOID BRAKE VALVE
Install a solenoid valve on the mounting bracket with the supplied hardware as shown
in the Parts Section in this manual. While installing the fittings to the brake valve, the
electical coil on the spool may have to be removed to make room. When reinstalling the
coil, it is important to use no more than 5 ft. lbs. (or 60in. lbs.) torque. WARNING: OVER
TORQUE TO THE COIL WILL RESULT IN HYDRAULIC FAILURE OF SPOOL.
(ASM-C-
0025)
TEMPERATURE GAUGE MOUNTING
(OPTIONAL)
Mount the temperature gauge where it is clearly visible to the operator. Attach the
green (-) wire from the negative post on the gauge to a grounded bolt on the tractor
frame. Remove paint if needed to make a good ground. Remove the pipe plug from the
side of the hydraulic reservoir and install the temperature sensor using thread sealing
tape. Run the white wire from the (s) sensor post of the gauge to the temperature sensor
on the hydraulic reservoir tank.
(ASM-C-0051)
