Therma-Stor Products Group Santa-Fe Rx Free-Standing Dehumidification User Manual
Page 2
Table of Contents
1. Specifications .......................................................................... 2
2. Installation .............................................................................. 2
2.1 Location .............................................................................. 2
2.2 Electrical Requirements ..................................................... 2
2.3 Condensate Removal ......................................................... 3
2.4 Optional Reservoir Container .............................................. 3
2.5 Safety Overflow Switch ...................................................... 3
3. Operation ................................................................................. 3
3.1 Top Removal ...................................................................... 3
3.2 Humidity Control Adjustment .............................................. 3
3.3 Power Switch ...................................................................... 3
4. Maintenance ........................................................................... 3
4.1 Air Filter ............................................................................. 3
4.1A Filter Options ................................................................. 4
4.1B Optional Filter Test ........................................................ 4
5. Service ................................................................................... 4
5.1 Warranty ............................................................................ 4
5.2 Technical description ......................................................... 4
5.3 Troubleshooting ................................................................. 4
5.4 Refrigerant Charging .......................................................... 5
5.5 Blower Replacement .......................................................... 5
5.6 Compressor/Capacitor Replacement .................................. 5
5.6A Replacing A Burned Out Compressor ...................................... 6
5.6B Replacing a Compressor - Nonburn Out .................................. 6
5.7 Humidity Control ................................................................ 6
5.8 Defrost Thermostat ............................................................ 6
5.9 Condensate Pump .............................................................. 6
5.10 Relay................................................................................ 6
5.11 Low Pressure Control ....................................................... 6
Wiring Diagram ............................................................................ 7
Service Parts List ........................................................................ 8
Filter Frame Assembly ................................................................ 9
Set-Up Instructions .................................................................... 10
Warranty .................................................................................... 11
Read the installation, operation and maintenance instructions
carefully before installing and using this unit. Proper adherence to
these instructions is essential to obtain maximum benefit from
your Santa Fe Rx Dehumidifier.
1. Specifications
Part Number:
4023673
Blower:
230 CFM @ 0.0" WG
Power:
630 Watts @ 80°F and 60% RH
Supply Voltage:
115 volt – 1 phase – 60 Hz
Current Draw:
5.4 Amps
Energy Factor:
2.45 l/kw
Operating Temp.:
45°F Min., 95°F Max. (70°F
recommended)
Sized for:
2200 Sq. Ft. - Typical
Minimum Performance at 80°F and 60% RH
Water Removal:
74 Pints/Day
Efficiency:
5.2 Pints/kWh
Air Filter:
MERV-11
Efficiency
Standard 65% Efficient, ASHRAE Dust
Spot Test
Size:
16" x 20" x 2'
Power Cord:
10' – 110-120 VAC, Ground
Drain Hose:
3/16" ID x 20' of drain hose with 15' lift
capacity; Internal Pump Included
Santa Fe Rx Dimensions
Dimensions with
Dimensions
Secondary Filter Housing
Shipping
Width:
23"
23"
29"
Height:
37-1/2"
37-1/2"
46"
Depth:
20"
24-5/8"
29"
Weight:
130 lbs
172 lbs.
CAUTION!
— This symbol means
important instructions. Failure to heed them can result
in injury or material property damage.
TABLE OF CONTENTS
2
Santa Fe Rx Installer’s & Owner’s Manual
