26

Description

1.

Steam control button

2.

Iron temperature control slide

3.

Iron thermostat light

4.

Ultracord system (depending on model)

5.

Iron rest

6.

Illuminated on / off switch

7.

Electric cord rewind button (depending on model)

8.

Power cord storage space

9.

Power cord and plug

10.

Turbo button (depending on model)

11.

Double protection cover.

12.

Carry handle

13.

Unlock button on protective cover

14.

Removable water tank

15.

Removable water tank handle

16.

Steam generator boiler (in the
base unit)

17.

Iron-base steam cord

18.

Slide storage place for the steam
cord

19.

Anti-scale valve cap

20.

Anti-scale valve

21.

Control panel

a.

Water tank empty” light

b.

“Auto off” light

c.

Restart button

d.

“Anti-calc” light

e.

“Reset” button

f.

“Steam ready” light

g.

Steam output control dial

Your generator is fitted with the “Protect Concept” system:
• Double protection cover.
• Cover automatically locks when it is folded up over the iron

-- ffiig

g..2

2

and open using the unlocking button -

ffiig

g..3

3 ..

• Carry handle

-- ffiig

g..1

1

Preparation

What water may be used ?

Your iron has been designed to operate using untreated tap water.

Heat concentrates the elements contained in water during evaporation. The
types of water listed below contain organic waste or mineral elements that can
cause spitting, brown staining or premature wear of the appliance: water from
clothes dryers, scented or softened water, water from refrigerators, batteries or air
conditioners, pure distilled or demineralised water or rain water should not be
used in your iron. Also do not use boiled, filtered or bottled water.

Filling the water tank

• Pull the cover up over the iron until the protection system automatically locks

(you will hear a “click” ) -

ffiig

g..2

2

• Remove the water tank by pulling on the handle (at the front of the generator)

fig.4.

• Fill the tank with water, taking care not to exceed the maximum level

fig.6.

and

fig.7.

• Slide the tank back into its housing until its “clicks” into place

fig.5.

• Press the unlocking button on the protective cover until you hear a click, and then

fold it back on to the generator base unit –

ffiig

g..3

3..

“PROTECT CONCEPT” safety system

• Your iron is equipped with an extension cord system to prevent the cord from

dragging over the laundry and creasing it again when ironing. It also keeps the cord
out of the way of your hand.
Ironing with the Ultracord system:
- The Ultracord system automatically tips back.
- Each time you put the iron back on its base, the Ultracord system fits into the heel
of the iron and opens back up automatically when you use the iron.
Storing the generator:
- Push the connector back in the heel.
- A magnet holds the connector to the heel, making your generator easy to store –

fig.8.

Ultracord System

(according to model)

Notice Protect 17L 1800111440 13/02/08 14:47 Page 26
