82
1 103 1062 Main frame F30 1
- 103 1063 Main frame F35 1
2 173 1098 Side cover LH 1
3 173 1099 Side cover RH 1
4 103 1064 Rear support tube 1
5 72 0813 100 1 Sleeve 2
6 533 1048 Move wheel 2
7 673 500 88 Cap 2
8 533 1067 Rear foot cover 4
9 M10 DIN 125 Washer 2
10 M10 DIN 127 Spring washer 2
11 M10x25 ISO 7380 Allen head screw 2
12 153 1025 Seat tube 1
13 373 1030 Locking knob 1
14 153 1026 Seat 1
15 373 1032 Tension control, F30 1
15 403 1108 AC. Adabtor, F35 1
16 223 1014 Tension connector, F30 1
16 403 1109 Servo motor, F35 1
17 403 1111 Meter wire, F30 1
- 403 1110 Meter wire, F35 1
18 403 1112 Sensor wire, F30 1
- 403 1114 Sensor wire, F35 1
19 M8x30 ISO 7380 Allen head screw 2
20 203 1054 Handle bar tube, F30 1
- 203 1055 Handle bar tube, F35 1
21 M5x35 DIN 7985 Screw, F30 1
23 403 1113 Pulse grip unit (incl. 22) 2
24 203 1057 Handle bar (incl. 34) 1
25 533 7039 End plug for handle bar 2
26 M8x25 DIN 912 Screw 1
27 233 1062 Meter, F30 1
- 233 1063 Meter, F35 1
28 M5x10 DIN 7985 Screw 2
29 353 1013 Crank L&R (incl. 31) 1
30 M8x25 DIN 933 Hex head screw 2
32 363 1010 Pedal, pair 1
33 533 1059 Handle bar tube insert 1
34 213 1012 Handle grip 2
35 533 1068 Seat post sleeve 1
36 533 1057 Seat post bottom insert 1
37 M4x10 DIN 7985 Screw 2
38 M4 DIN 9021 Washer 1
39 3,5x8 DIN 7981 Screw 1
40 503 7017 Sensor bracket 1
41 3,5x13 DIN 7504-M Screw 1
42 M6x10 DIN 7985 Screw, F35 4
43 M6x20 DIN 933 Screw 4
44 503 7011 Safe bracket 1
45 263 1009 Pulley 1
46 343 1012 Axle for pulley 1
47 M6 DIN 985 Nylock nut 5
48 443 1010 Belt 1
49 403 7017 Magnet 1
50 17 DIN 471 C-clip 1
51 303 1018 Flywheel 1
52 343 1013 Flywheel axle 1
53 373 1028 Magnet bow 1
54 523 504 84 Bearing 4
55 523 1022 Bearing 1
56 523 1023 Metal sleeve 1
57 523 1024 Spacer sleeve 1
58 263 1010 Drive pulley 1
59 12 DIN 471 C-clip 3
60 M10 DIN 125 Washer 2
61 653 7026 WH nut 3/8” 2
62 M8x68 DIN 933 Screw 1
63 513 1009 Belt tightener frame 1
64 523 409 85 Bearing 1
65 533 1058 Drive belt wheel 1
66 643 1010 Garge spring 1
67 653 1029 Nylon washer 2
68 M8x25 DIN 912 Screw 1
69 M8 DIN 985 Nylock nut 2
70 M8 DIN 9021 Washer 1
71 M6 DIN 934 Self-locking nut 1
72 643 7002 Spring 1
73 M6x65 DIN 933 Screw 1
74 503 1027 Magnet holder bracket 1
75 M8 DIN 127 Spring washer 2
76 M8x20 DIN 933 Screw 2
77 653 1030 WH nut M6 1.57mm 2
78 653 7027 Nylon washer 1
79 223 1015 Wire rod, F35 1
80 503 1028 DC-wire bracket, F35 1
81 4x12 DIN 7981 Screw, F35 2
82 403 1115 DC wire, F35 1
83 M8 DIN 125 Washer 2
84 533 1066 Plug, F30 1
85 M8x60 DIN 933 Screw 1
- 423 1137 Label set F30 1
- 423 1138 Label set F35 1
- 553 101 88 Screw - shaped 1
- 553 100 88 Multi purp. wrench 1
- 556 032 00 Allen key 6 mm 1
- 583 1033 Owner’s manual 1
