T

T

T

S

S

S

5

5

5

1

1

1

2

2

2

M

M

M

/

/

/

1

1

1

G

G

G

/

/

/

2

2

2

G

G

G

S

S

S

D

D

D

O

O

O

M

M

M

7

7

7

H

H

H

7P Horizontal Type

SATA Flash Modules


Transcend Information Inc.

V1.2

6

Functionality

Pin Assignments

Pin No.

Pin Name

01 GND

02 A+

03 A-

04 GND

05 B-

06 B+

07 GND

Disk Active

Indicator

Write-Protect

Disabled
