Transcend Information TS2GSDOM7H User Manual
Page 2
T
T
T
S
S
S
5
5
5
1
1
1
2
2
2
M
M
M
/
/
/
1
1
1
G
G
G
/
/
/
2
2
2
G
G
G
S
S
S
D
D
D
O
O
O
M
M
M
7
7
7
H
H
H
7P Horizontal Type
SATA Flash Modules
Transcend Information Inc.
V1.2
2
Specifications
Physical Specification
Form Factor
SATA Flash Module Horizontal Type
Storage Capacities
512M~2GB (T.B.D)
Length
40.0
± 0.3
Width
30.0
± 0.2 (Not including Write-Protect Switch and SATA connector)
Dimensions (mm)
Height
24.3
± 0.5 (refer to mechanical drawing)
Input Voltage
5V
± 10% / 3.3V ± 5%
Weight
8 g
Connector
Signal: SATA 7 pins female connector with latch
Power: 2P 1.5mm pitch wafer connector
Environmental Specifications
Operating Temperature
0
℃
to 70
℃
Storage Temperature
- 40
℃
to 85
℃
Power Consumption
Crystal Disk Mark 1.0.6 / 50MB
Read
164 mA(average) / 200 mA(peak)
Write
170 mA(average) / 210 mA(peak)
2GB SATA Flash Modules
Power Consumption
(DC 5V
@
25
℃
)
Standby
129.4 mA
