Troy-Bilt 42027 - Manual (Page 5)

5
Ref. # Part # Description Qty. Ref. # Part # Description Qty.
Model 42027
1 1724791 Push-On Cap .......................................... 1
2 1735868 Knob....................................................... 1
3 1890945 Flat Washer, 3/8 ..................................... 1
4 1749283 Chute Control Crank ............................... 1
5 1185147 Cotter Pin, 3/32 x 5/8 ............................. 2
7 1177625 Roll Pin, 1/8 x 3/4 .................................. 2
8 1773919 Chute Control Shaft ............................... 1
9 1774114 Crank Support ........................................ 1
10 1724870 Worm Gear............................................. 1
11 1186329 Flange Bolt, 5/16 –18 x 3/4 .................... 1
12 1724885 Drive Pin, 3/32 x 3/4............................... 1
13 1735869 Gear Support.......................................... 1
14 1100255 Flat Washer, 5/16 ................................... 1
15 1732499 Locknut, 5/16–18 ................................... 8
16 1100068 Hex Bolt, 3/8–16 x 3/4............................ 2
17 1759142 Cap Assembly (Incl. Ref. 18).................. 1
18 1750692 Warning Decal........................................ 1
22 1771723010 Chute ..................................................... 1
23 1107383 Flat Washer, 3/8 ..................................... 8
25 1752461 Sems Screw , #10–24 x 7/8 ................... 6
26 1772333 Locknut, #10–24 .................................... 9
27 1103959 Flat Washer, #10 .................................... 6
28 1724869 Hold Down Clip ...................................... 3
30 1103195 Hex Bolt, 5/16–18 x 5/8.......................... 3
31 1185809 Ball Bearing ............................................ 1
32 1739488 Bearing Retainer..................................... 1
33 1774210 Housing Assembly (Incl. Ref. 34)............ 1
34 1750691 Warning Decal........................................ 1
35 1750969 Plug........................................................ 2
36 1734398 Locknut,1/4–20 ...................................... 6
37 1186126 Carriage Bolt, 3/8–16 x 3/4..................... 4
38 1186391 Flange Locknut, 5/16–18........................ 5
39 1712059 Carriage Bolt, 5/16–18 x 1/2................... 5
40 1749281010 Scraper Blade ......................................... 1
41 1728567010 Runner ................................................... 2
42 1733398 Locknut, 3/8–16 ..................................... 8
43 1720922 Support Bearing ..................................... 2
44 1185846 Flange Bushing....................................... 2
45 1100257 Flat Washer, 1/2 ..................................... 2
46 1100245 Lockwasher, 1/2..................................... 2
47 1100053 Hex Bolt, 1/2–13 x 3/4............................ 2
48 1111599 Hex Bolt, 1/4–20 x 5/8............................ 6
49 1185816 Special Washer....................................... 8
50 1740491001 Left Auger Blade..................................... 1
51 1740490001 Right Auger Blade .................................. 1
52 1750515 Shear Bolt, 5/16–18 ............................... 2
53 1740462001 Impeller ................................................. 1
54 1185348 Roll Pin, 1/4 x 1-1/4 ............................... 1
56 1200033 Key, 3/16 x 3/4 ....................................... 1
57 1733185 Square Set Screw, 5/16–18 x 5/8........... 2
58 1750703 Belt Guide............................................... 2
59 1714243 Nylon Bushing........................................ 1
60 1185984 Flange Nut .............................................. 1
61 1753356 Sleeve..................................................... 1
62 1752460 Shim....................................................... 3
63 1766808 V-Belt– 36" ............................................. 1
64 1725282 Caster Sheave......................................... 1
65 1757859 Logo Decal ............................................. 1
66 1714782 Swivel Block .......................................... 1
69 1724491 Flange Bolt, 5/16–18 x 3/4 ..................... 4
73 --- Not used.................................................
74 1719271 Shim Washer.......................................... 1
75 1737957 Nylon Washer......................................... 2
76 1737499 Grip ....................................................... 1
77 1723643 Adjusting Lever ..................................... 1
78 1771274 Chute Deflector ...................................... 1
79 1737940 Truss Head Bolt. 10-24 .......................... 3
80 1740471001 Gear Case Assembly
(See Breakdown page 7) ..................... 1
81 1757861 Logo Decal ............................................. 2
202 1757032 Loctite #242, .02 oz. .............................. NI
NI Item not included with unit. Order separately.
A/R As Required
