3
Ref. # Part # Description Qty. Ref. # Part # Description Qty.
Model 42027
1 1703539 Handle Grip ............................................ 2
2 1750796 Bumper .................................................. 2
3 1107381 Flat Washer, 1/4 ..................................... 11
4 1111601 Hex Bolt, 1/4–20 x 1-3/4 ........................ 2
5 1734398 Locknut, 1/4–20 ..................................... 7
6 1745672001 Control Lever.......................................... 1
7 1771727 Drive Cable ............................................ 2
8 1754177010 Handlebar - right hand .......................... 1
9 1745673001 Control Lever.......................................... 1
10 1749977001 Cable Bracket ......................................... 2
11 1752500 Extension Spring .................................... 2
12 1754128 Thread Forming Screw, 1/4–20 x 3/4 ..... 2
13 * Tecumseh Engine, Model HSK60 ........... 1
14 1104435 Woodruff Key, 1/8 x 5/8 ......................... 1
15 1759446 PTO Sheave............................................ 1
16 1103441 Set Screw, 1/4–20 x 3/8 ......................... 2
17 1108852 Square Key, 3/16 x 3/4 ........................... 1
18 1185596 Set Screw, 5/16–18 x 5/16 ..................... 2
19 1771238 Engine Sheave........................................ 1
20 1754175 Belt Cover............................................... 1
21 1115815 Truss Screw, #10–24 x 5/8 .................... 2
22 1729440 Idler Pulley ............................................. 1
23 1100243 Lockwasher, 3/8..................................... 2
24 1186231 Hex Nut, 3/8–16 ..................................... 2
25 182087 Link – Offset........................................... 1
26 1751017 Idler Arm Stop........................................ 1
27 1759444 Idler Arm ............................................... 1
28 1724492 Thread Forming Screw, 1/4–20 x 1/2 ..... 5
29 1100242 Lockwasher, 5/16................................... 5
30 1748659 Spacer .................................................... 2
31 1111608 Hex Bolt, 5/16–18 x 2-1/2 ...................... 2
32 1715538 Bearing - Nyliner .................................... 4
33 1740102 Torsion Spring ....................................... 2
34 1100257 Flat Washer, 1/2 ..................................... 1
35 1100255 Flat Washer, 5/16 ................................... 7
36 1774473 Drive Chain #41...................................... 1
37 1185013 Connector Link ....................................... 1
38 1200033 Hi-Pro Key, 3/16 x 3/4............................ 1
39 1740100 Transmission (See breakdown, page 6)... 1
40 1740139010 Reinforcement Bracket ........................... 1
41 1766984 Thread Forming Screw, 5/16–18 x 3/4 ... 2
42 1737041 Handle Grip ............................................ 1
43 1774124010 Shift Handle ........................................... 1
44 1186327 Flange Lock Bolt, 5/16–18 x 1/2............. 18
45 1186391 Flange Locknut, 5/16–18....................... 6
46 1758264010 Doubler Plate Assembly ......................... 1
47 1749291010 Rear Cover ............................................. 1
48 1757862 Shift Decal.............................................. 1
49 1739463 Flat Washer ............................................ 4
50 1739470 Bearing................................................... 2
51 1773892010 Frame .................................................... 1
52 1750799 Rubber Pad ............................................ 1
53 1749299010 Frame Cover .......................................... 1
54 1724760 Clevis Pin ............................................... 2
55 1717897 Hair Pin .................................................. 2
56 1755827 Tire, 4.10/3.50 x 6.00 ............................. 2
57 1760189 Wheel Rim.............................................. 2
58 1718086 Valve Stem ............................................ 2
59 1100029 Hex Bolt 5/16–24 x 5/8........................... 1
60 1750704 Belt Guide............................................... 2
61 1100044 Hex Bolt, 5/16–18 x 3/4.......................... 2
62 1740127 Transmission Sheave ............................. 1
63 1733185 Set Screw, 5/16–18 x 5/8 ....................... 2
64 1186328 Flange Screw, 5/16–18 x 5/8.................. 4
65 1759447 Belt Guide............................................... 1
66 1100351 Cotter Pin, 1/8 x 1-1/4............................ 2
67 1186299 Flange Screw, #10-32 x 3/8.................... 1
69 1710566 Flat Idler ................................................. 1
70 1746379 V-Belt ..................................................... 1
71 1771750 Brake Arm .............................................. 1
72 1185986 Speed Nut, #10 ...................................... 2
73 1100002 Hex Bolt, 1/4–28 x 3/4............................ 1
74 1100241 Lockwasher, 1/4..................................... 1
75 1740124 Spacer .................................................... 1
76 1748443 Idler Arm ................................................ 1
77 1758184 Axle ....................................................... 1
78 1720717 Belt Guide............................................... 1
79 1100004 Hex Bolt, 5/16–24 x 3/4.......................... 3
80 1758259 Belt Guide............................................... 1
81 1754158 Bracket ................................................... 1
82 1754159 Cable Clamp ........................................... 2
90 1753986 Key ......................................................... 2
91 1727321 Ignition Switch Assembly (Incl. Ref. 90).. 1
94 1771728 Nyliner Bearing ...................................... 2
95 1185585 Grommet ................................................ 1
96 1100254 Flat Washer, 1/4 ..................................... 4
98 1774112 Decal, Logo ............................................ 1
99 1774209 Console (Incl. Ref. 208) ......................... 1
100 1100811 Hex Screw, 1/4-20 x 1-1/2 ..................... 4
101 1754176010 Handlebar - left hand.............................. 1
109 1748393 Carriage Bolt, 3/8-16 x 1-3/4.................. 2
200 1900706 Red Spray Paint, 13 oz. can .................. NI
201 1735222 Black Spray Paint, 13 oz. can ................ NI
202 1757032 Loctite #242, .02 oz. .............................. A/R
203 1725381 Tire Chains ............................................ NI
204 1760190 Wheel and Tire Assembly,
(Incl. Refs. 56, 57 & 58)...................... 2
205 1774199 Service Kit .............................................. 1
206 1771748 Lead Assembly ....................................... 1
207 1774122 Bracket, Shift Decal ................................ 1
208 1773817 Decal, Instructions ................................. 1
*
Order parts from your local Tecumseh Power Products dealer. Refer to engine for model number, type number and code.
NI Item not included with unit. Order separately.
A/R As required.
