TPA3001D1EVM Bill of Materials
3-2
3.1 TPA3001D1EVM Bill of Materials
Table 3–1. TPA3001D1EVM Bill of Materials
Reference Description Size Qty MFG. Part Number
C1, C2 Capacitor, ceramic, 0.47
µ
F, 80%/–20%, Y5V,
16 V
0805 2 Panasonic ECJ–2VF1C474Z
C3–C6, C10, C11 Capacitor, ceramic, 1
µ
F, 80%/–20%, Y5V, 25 V 0805 7 Panasonic ECJ–2FF1E105Z
C7 Capacitor, electrolytic, 10
µ
F, 35 V, SMD D 1 Panasonic ECS–T1VD106R
C8,C9 Capacitor, ceramic, 0.22
µ
F, 80%/–20%, Y5V,
16V
0805 2 Panasonic ECJ–2VF1C224Z
C12 Capacitor, ceramic, 220 pF, ± 10%, X7R, 50 V 0805 1 Panasonic ECU–V1H221KBN
C14,C15 Capacitor, ceramic, 1000 pF,
±
10%, X7R, 50 V 805 2 Panasonic ECJ–2VB1H102K
L1, L2 Ferrite Bead, 0.05
Ω
, DCR, 70
Ω
at 100 MHz,
3 A
1206 2 Fair–Rite 2512067007Y3
R1, R2, R3, R4 Resistor, chip, 120 k Ω , 1/10 W, 5% 0805 4 Panasonic ERJ–6GEYJ124V
R5 Resistor, chip, 0 Ω , 1/10W, 5% 805 1 Panasonic ERJ–6GEY0R00V
R6, R7 Resistor, chip, 51
Ω
, 1/10 W, 5% 0805 2 Panasonic ERJ–6GEYJ510V
D1, D2 Schottky diode, Vfm = 0.5 V at 1 A, Vr = 30 V SMA 2 Diodes, Inc. B130–13
J1(GAIN0),
J2(GAIN1) Header, 2 position, male 2mm 2 Norcomp 2163–36–01–P2
Shunts 2mm 2 Specialty
Electronics 2JM–G
S1 (SHUTDOWN) Switch, momentary pushbutton, 12 V, 50 mA 1 Panasonic EVQ–PJS04K
PnP pins Headers, 0.1 inch centers, 1/2 inch long 10 Sullins PZC36SABN
U1 TPA3001D1PWP 24-pin
TSSOP 1 TI TPA3001D1PWP
